MOTORISED PARASOL

The PAN EVO is a new-generation retractable parasol, ideal for the terraces of hotels, restaurants, bars and lounge areas.

Its matt-finished aluminium frame ensures excellent weather resistance whilst maintaining a modern and refined aesthetic.

The built-in motor allows for automatic opening and closing, controlled by an HF radio remote control, which also includes locking and control of the LED lighting (depending on the configuration).

The nylon components, cataphoresis-treated steel and stainless steel fastenings guarantee exceptional durability, even in a marine environment.

The solution-dyed acrylic fabric offers excellent colour fastness and optimum UV protection.

The wind-resistant system with an aluminium vent improves ventilation and stability in windy conditions.

Available in a wide range of MAXI colours, the PAN EVO suits all styles of outdoor design.

Technical details

• Motorised retractable parasol

• Frame: matt-finished aluminium

• Components: nylon + cataphoresis-treated steel + stainless steel fasteners

• Arms: matt-finished aluminium

• Control: HF radio control (opening, closing, locking, lighting)

• Fabric: solution-dyed acrylic + matching edging

• Wind-resistant system: chimney with aluminium frame

• Available shapes: round, square, rectangular

• Colour range: MAXI range

• Use: commercial (terraces, hotels, restaurants, bars)

Full dimensions

Round model

Ø 350 cm

A: 319 cm

B: 325 cm

C: 30 cm

D: 238 cm

E: 102 cm

F: 440 cm

G: 350 cm

H: 90 cm

Square models

250 × 250 cm

A: 281 cm

B: 294 cm

C: 25 cm

D: 224 cm

E: 115 cm

I: 340 cm

L: 250 cm

M: 90 cm

300 × 300 cm

A: 305 cm

B: 316 cm

C: 30 cm

D: 240 cm

E: 99 cm

I: 390 cm

L: 300 cm

M: 90 cm

350 × 350 cm

A: 314 cm

B: 323 cm

C: 30 cm

D: 239 cm

E: 71 cm

I: 440 cm

L: 350 cm

M: 90 cm

Rectangular model

300 × 400 cm

A: 311 cm

B: 320 cm

C: 30 cm

D: 240 cm

E: 65 cm

N: 390 cm

O: 400 cm

P: 90 cm

Weight & packaging

Ø 350 cm

• Weight: 40 kg

• Parasol: 40 × 340 × 68 h cm

• Base frame: 132 × 90 × 35 (h) cm

• Concrete slabs: 100 × 120 × 35 (h) cm

250 × 250 cm

• Weight: 38 kg

• Packaging dimensions

300 × 300 cm

• Weight: 40 kg

• Same packaging

350 × 350 cm

• Weight: 43 kg

• Same packaging

300 × 400 cm

• Weight: 45 kg

• Same packaging

-(Also available in a non-motorised version)
